The XRMI has 6 pads armed on 6 independent arms, 25button electrodes on each pad, total 150 curves be recorded, can get resistivity image after processing. The new design can make the image more clear and work well in higher salinity drilling fluid.
Applications:
- Determine dips and strikes
- Identify and describe faults and fractures
- Obtain sedimentary and stratigraphic interpretations Structural mapping
- Make well-to-well correlations
- Unconformity mapping
- Delineating other geological structures.
Features and benefits:
- Data acquisition in high Rxo:Rt ratio formations
- Enhances image quality
- Combinable with the Ultrasonic Xplorer Evaluates geological and petro physical formation features in detail Reduces rig time Powered standoffs with independent
- six-arm pad carriers Improves data quality in deviated and horizontal well profiles
